Import Blast Holes

Select Holes to Import panel

Use Import Blast Holes to import values from a nominated CSV ( Comma Separated Values) file into the blastholes of the currently active blast.

Diagram 1 CSV file format (as viewed through Vulcan Text Editor)

In the example shown above the first line of the CSV file is used to identify the case sensitive variable names, i.e. iron (fe) and silica (sio2), with the following entries containing field values and hole numbers. A single alphanumeric character, in this case a comma, has been used to separate each variable and its value.

Instructions

On the Grade Control menu, click Import Blast Holes to display the Import Blast Holes panel.

After completing the Import Blast Holes panel, click OK to display the Import Options panel.

Click OK to display the Select Holes to Import panel.

Hole Name

This column cannot be edited.

Hole Exists

This column cannot be edited.

Method

Depending on the options selected in the Import Options panel, you will be able to use the drop-down menu to chose between updating the hole or replace the hole.

Import

Select which holes will be imported. By default, all holes are selected.

Click OK to import holes.
